Hybrid Spark Gap
Hybrid Spark Gap (HSG) high-energy surge diverters are designed for point-of-entry protection at main switchboards, particularly in locations where power grid instability is a concern.

Hybrid Protection
The Hybrid Spark Gap design combines a spark gap and a Metal Oxide Varistor (MOV) connected in series to enhance the overvoltage withstand capability of the surge protection device.This hybrid configuration allows the HSG to tolerate continuous overvoltage of up to 480 V while still maintaining a low protection (clamping) voltage level.

LED Status Active Display
The LED status display provides visual indication of the condition of each protection segment.
- Brightly illuminated LEDs indicate normal operation.
- A dim LED indicates failure of an external backup fuse and activates the external alarm.
- An extinguished LED indicates internal component failure or thermal overload, which also activates the external alarm.

Safe Metal Enclosure
Shogun power protection products are housed in robust, all-metal enclosures to ensure maximum safety. In the event of prolonged overvoltage conditions, the enclosure will not ignite or explode, reducing the risk of fire and equipment damage.

Standard
EN/IEC Type1/Class A, CE approved cetificated, IEC 61643-11:2011 Class I, AS/NZS 1768:2007,
UL 1449 3rd edition, IEEE 62.41.2:2002, ISO9001:2015 NQA, ISO14001

Download : Datasheet
